IGLO ENERGY CLASSIC PSK UPVC Tilt and Glide Patio doors

• MACO SKB-S System Standard fittings for window sashes weighing up to 160 kg
• 3-glazed (2-chamber) units infilled with argon gas, with Ug = 0.5 W/(m²K)
• profile core in white
• galvanised steel glass-pane spacer optional Swisspacer Ultimate glass-pane spacer
• 2 EPDM gaskets in black (external and internal) + 1 central gasket made of foamed EPDM, gaskets available in black
• gasket filling the lower fittings groove
• 2 mm full (closed) steel frame reinforcement, „c”-shaped steel sash reinforcement
• aluminium handle
• rail cover available in 4 colours: silver, white, light brown and brown
• 5-chamber PVC under-sill trim with a gasket

Class A 7-chamber profile, made exclusively from virgin material. Our proprietary system provides optimum light to both large and small rooms, while maintaining exceptional thermal insulation parameters to significantly reduce heating bills.

EPDM gaskets:

3

THERMAL TRANSMITTANCE:

Uw = 0,66 W/(m2K)*

NUMBER OF CHAMBERS:

7

INSTALLATION DEPTH:

82 mm

Glass packages:

24-52 mm

Class profile:

A
