MB77 HS Lift & Glide 4 part Patio doors
MB77 HS Lift & Glide 4 part Patio doors
A premium 4-panel aluminium sliding system designed for large panoramic openings up to 13 metres wide, combining advanced thermal insulation, smooth lift & slide operation, and sleek aesthetics.
Features
Features
- Suitable for large-scale openings up to 13 m wide
- Advanced lift & slide hardware for effortless operation
- Twin-track system with smooth sliding for large, heavy sashes
- Superb thermal and sound insulation with optional acoustic or solar glass
- Space-saving design with no inward swing radius
- Optional smart control for automated opening
- Highly secure with night vent locking and burglar-resistant hardware
- Full air and watertight sealing with EPDM gaskets
- Customisable in style, colour, finish, and glazing
Specifications
Specifications
- System Type: Multi-chamber aluminium lift & slide door
- Configuration: 4-part, twin-track system
- Max Dimensions: Up to 13 m width x 2.6 m height
- Frame Depth: 174 mm
- Sash Depth: 77 mm
- Max Glazing Thickness: Up to 55 mm
- Compatible System: MB-86
- U-Value (Standard Double Glazed): ~1.0 W/(m²K)
- Optional U-Values:
- Sash Weight Capacity: Up to 400 kg
- Opening System: Manual or automatic (remote-controlled) lift & slide
- Threshold: Flush aluminium threshold with thermal break
- Colours: 200+ RAL colours, woodgrain and textured finishes
- Security: PAS 24 compliant
- Glazing Options:
- Standard: 4 mm toughened Low-E Thermofloat, Swiss spacer, argon-filled
- Optional: Triple/quad glazing, acoustic, solar control, laminated or security glass
